Product Description

3M 468MP adhesive transfer tape is a clear, 5.2 mil acrylic adhesive film designed for industrial bonding and graphic attachment. It consists of a high performance acrylic adhesive layer supplied on a polycoated kraft paper liner.

The adhesive is suited for long-term attachment where high shear strength and environmental resistance are required. The 5.2 mil thickness supports bonding when light surface texture is present on one or both substrates.

It provides resistance to humidity, water exposure, and common industrial chemicals. Short-term temperature resistance supports demanding processing and operating conditions.

• High shear strength to resist edge lifting and slippage
• 5.2 mil adhesive thickness for textured surface bonding
• Short-term temperature resistance up to 204 °C
• Resistance to solvents, mild acids, and alkalis
• Stable bond performance in humid environments
• Initial repositionability during placement on plastics

Typical uses include graphic nameplates, membrane switch assembly, laminated industrial gaskets, and precision electronic component bonding.

Surfaces should be clean and dry prior to application. Uniform pressure during lamination and installation supports optimal bond development.

Specifications

Attribute	Value	Test Method
Adhesive Type	Acrylic adhesive 200MP
Total Thickness	0.13 mm (5.2 mil)	ASTM D3652
Liner Material	Polycoated kraft paper
Liner Thickness	0.11 mm (4.2 mil)
90° Peel Adhesion (Stainless Steel)	11.8 N/cm	ASTM D3330
180° Peel Adhesion (Stainless Steel)	15.1 N/cm	ASTM D3330
Overlap Shear Strength	19.0 N/cm²	ASTM D1002
Dielectric Strength	26.5 V/mil	ASTM D149
Short-Term Temperature Resistance	204 °C
Long-Term Temperature Resistance	149 °C
