Black Glass Cloth Electrical Tape

Black Glass Cloth with Thermosetting Rubber Adhesive

High adhesion. Solvent and tear resistant. Coil insulation wrap, relay coverings, protective insulating wrap on solenoid coils, splicing. Black, White. MIL-T-4053B Along with its high adhesion and resistance to tearing, this tape offers a rubber thermosetting adhesive system that gives it excellent solvent resistance. Applications include coil insulation wrapping, relay coverings, protective insulating wrap on solenoid coils, splicing on electrical transmission lines, making it ideal for motor repair shops for bundling and banding heavy gauge magnet wire. The Woven fiberglass backing imparts high temperature resistance and thermal stability and offers outstanding abrasion resistance for a large number of applications. This tape offers high adhesion and resistance to tearing. Excellent solvent resistance due to the rubber thermosetting adhesive system.

The Intertape 4616 Woven fiberglass backing imparts high temperature resistance and thermal stability and offers outstanding abrasion resistance for a large number of applications. This tape offers high adhesion and resistance to tearing. Excellent solvent resistance due to the rubber thermosetting adhesive system.

Backing	Glass Cloth
Backing Thickness	5.0 mil
Adhesive	Rubber Thermosetting
Color	White, Black
Total Thickness	7.0 mil
Dielectric Strength	2500 Volts
Temp. Class	155� C / F
Insulation Resistance	103 megohms
Tensile Strength	175 lbs/in
Adhesion to Steel	50 oz/in
Elongation	3%
Electrolytic Corrosion	1.0 Direct/ A, 1*
Flammability	BU 2*
Storage Stability	Very Good
Solvent Resistance	Excellent
Moisture Resistance	Excellent
UL File #	E20780
CSA File #	LR94980

Ideal for coil insulation wrap, relay coverings, protective insulating wrap on solenoid coils, splicing on electrical transmission lines. Ideal for motor repair shops for bundling and banding heavy gauge magnet wire.

Black Glass Cloth Electrical Tape 2" x 60yds
